Crimping Force: |
200T |
Model: |
YJD2000 |
Item: |
16105 |
Crimping Type: |
Hexa |
Hight: |
48mm Approx |
Stroke: |
35mm |
200T Hydraulic Press Machine Crimping Form Hexagon Crimping Range 14-90mm
Split-type Hydraulic Crimping Pliers Production:
|
Item number |
16103 | 16103A | 16104 | 16105 | 16106 |
|
Model |
YJD-600 | YJD-1000 | YJD-1250 | YJD-2000 | YJD-3000 |
|
Crimping force |
60T | 100T | 125T | 200T | 300T |
|
Crimping range |
14-55mm | 14-76mm | 14-76mm | 14-90mm | 14-100mm |
|
Crimping type |
hexagon crimping |
hexagon crimping |
|||
|
Stroke |
24mm | 24mm | 35mm | 35mm | |
|
Heigth |
approx.370mm | approx.480mm | |||
|
(KG) Weight |
approx.N.W20KG G.W30KG |
approx.N.W30KG G.W40KG |
approx.N.W50KG G.W60KG |
approx.N.W85KG G.W95KG |
approx.N.W120KG G.W130KG |
|
Package |
wooden case | wooden case | |||
200T Hydraulic Press Machine Crimping Form Hexagon Crimping Range 14-90mm
Configuration:Working with an electric hydraulic pump or a petrol power hydraulic pump ( 80 MPa )
Hydraulic pump should be the rapid super high pressure hydraulic pump (double stage pump out put)
Hydraulic Crimping Machine 200T Hydraulic Crimping Head for Crimping ACSR1440
1. Donghuan Brand
2. 200T hydraulic pressing machine
3. Die size can accoridngly make per your drawings
4. work with 80 Mpa hydraulic electrical pump or gasoline pump
5. Hydraulic aluminum tube and steel tube pressing machine
