Weight:
|
105kg
|
Name:
|
Cable Winch
|
||||
|
Engine:
|
4HP Diesel
|
Feature:
|
Protable
|
Slow:
|
30KN
|
Fast:
|
18KN
|
3 Ton Portable Cable Winch Puller With Diesel Engine 4HP in Power Line Construction
3 Ton Portable Cable Winch Puller With Diesel Engine 4HP
Application
It is mainly used for power transmission and transformation project (including underground power cable engineering), telecommunications, communications engineering construction tower erection, traction cable, tighten the wire, lifting weights and tools, especially suitable for small batch job in the city.
Winch can be modified as per requirement, such as changing curve capstan into straight even cylindrical shape and coming with steel rope.
Features
1.Speedy and Efficient;
2.Safe and Reliable;
3.Compact structure;
4.Small volume;
5.Light in weight;
Technical Data of 3 Ton Portable Cable Winch Puller With Diesel Engine 4HP
| Model Type | Engine Power | Weight(kg) | Gear | Speed(m/min) | Pull Force(KN) |
| JJM3-C | Diesel Engine | 105 | Slow | 4 | 30 |
| Fast | 8 | 18 | |||
| Reverse | 4 | No Lifting |
