Type: |
916 Series |
Dia: |
916 *110mm |
Conductor: |
LGJ720 |
Used: |
Releasing 4 Conductors |
Sheave: |
5 |
Material: |
MC NYLON SHEAVE |
Stringing Equipment Tools Stringing Block Five Wheel Conductor Pulleys
|
Item number |
Model |
Number of sheaves |
Rated load (kN) |
Weight (kg) |
Features |
| 10151 | SHDN916 | 1 | 50 | 51 |
MC MC nylon sheave |
| 10152 | SHSQN916 | 3 | 75 | 120 | |
| 10153 | SHWQN916 | 5 | 150 | 200 |
Configuration:
1.Maximum suitable conductor ACSR720.
2.Sheave dimension ( outside diameter× root diameter × sheave width) Φ916×Φ800×110(mm).
3.The middle sheave can be customized as cast steel sheave.
