Engine Type: |
Electric Engine |
Power: |
3.0kw |
Rated Pressure: |
80 Mpa |
Max Oil Pressure: |
94Mpa |
Pump Output: |
Double Stage |
Weight: |
45kgs |
Application
Application of Honda hydraulic pump: to provide power for the cutting tool, the hydraulic compressor, punching machine
and other construction machinery, which is operated in the wild field in electric power, railway, rescue, construction and other industries.
| Item number | Model | Engine Tyde | Power |
Rated Pressure(Mpa) |
Max Oil
Pressure(Mpa) |
Rated Flow(L/min) | Weight(KG) | |
| Hig | Low | |||||||
| 16146A | YBQA-80-03 |
Gasoline engine |
5.0HP | 80 | 94 | 2.05 | 11.02 | 55 |
| 16147A | YBCA-80-03 |
Diesel engine |
4.0HP | 80 | 94 | 2.05 | 11.02 | 65 |
| 16144A | YBDA-80-03 |
Electric engine |
3.0KW | 80 | 94 | 1.6 | 8 | 45 |
Electromagnetic valve control to withdraw piston in any position
High and low speed two stage for quick oil output. turbine oil absorption could ensure max, effective oil volume
pressure safety valve over pressure unit could avoid over pressure damage
at 700kg/cm2, automatically pressure release
high pressure is for driving piston and low pressure is for piston reset
Oil pipe fitted with quick coupling could be ordered at any length
oil pipe coupling fitted with PT 3/8 " thread
