Model: |
LBGR100J |
Name: |
A-shape Gin Pole |
Type: |
With Manual Winch |
Materail: |
Aluminum Alloy |
Output: |
5 KN |
Max Length: |
19 M |
Aluminum Alloy Tubular A-Shape Gin Pole With Manual Winch For Tower Erection
This aluminum alloy tubular A-shape gin pole is ideal for setting up a small single pole as a whole or lifting moderate weight of components in the transmission and distribution lines construction. Its safety factor can reach 2.5. The maximum output force of hand crank winch is up to 5kN.
Uses: Aluminum Alloy Tubular A-Shape Gin Pole With Manual Winch For Tower Erection,For small pole erection in line construction
Notes:Aluminum Alloy Tubular A-Shape Gin Pole With Manual Winch For Tower Erection
1. The maximum output force of the manual winch is 5 kN
2. Use high strength aluminum alloy tube as main materials, steel parts are galvanized.
3. Fixed style head part mounted with tri-pulley
4. The safety factor is 2.5
5. Recommend using 7mm steel wire rope, the workable length is 9 times the length of the gin pole
6. Recommend using iron hoisting block (#11203, hook type).
Aluminum Alloy Tubular A-Shape Gin Pole With Manual Winch For Tower Erection Technical Data
| Item Number | Model | Base Stroke (m) | Allowable Vertical Load without Winch (kN) | Applicable Wire Pole in Use of Hand Crank Winch | Weight (kg/m) | |||
| Maximum Length (m) | Maximum Weight (kg) | |||||||
| Hoisting Directly | Using Double Sheave Block | Using Triple Sheave Block | ||||||
| 03331 | LBGR100J-6 | 2.1 | 18 | 9 | 600 | 720 | 5.5 | |
| 03332 | LBGR100J-7 | 2.4 | 13 | 11 | 550 | 700 | ||
| 03341 | LBGR120J-6 | 2.1 | 30 | 9 | 550 | 1050 | 1280 | 7.5 |
| 03342 | LBGR120J-7 | 2.4 | 26 | 11 | 550 | 870 | 1040 | |
| 03343 | LBGR120J-8 | 2.8 | 21 | 13 | 700 | 840 | ||
| 03351 | LBGR150J-8 | 2.8 | 31 | 13 | 550 | 1100 | 1500 | 8 |
| 03352 | LBGR150J-9 | 3.1 | 28 | 15 | 550 | 1100 | 1500 | |
| 03353 | LBGR150J-10 | 3.5 | 24 | 17 | 550 | 1050 | 1280 | |
| 03354 | LBGR150J-11 | 3.8 | 20 | 19 | 550 | 980 | 1160 | |
