Brand: |
DONGHUAN |
Model: |
ST12 |
Rated Load: |
12KN |
Hook Groove Length: |
120MM |
Name: |
Conductor Lifter |
Type: |
Overhead Transmission Line Tools |
Rated Load 12KN ST Model Conductor Lifter Overhead Transmission Line Tools
Quick Information:
Brand: Dong Huan Brand
Model: ST12
Rated Load:12KN
Hook Groove length(mm): 120mm
Type: Transmission line stringing tools
Specification:
| Model | Rated load(KN) | Hook groove length(MM) |
| ST12 | 12 | 120 |
| ST25 | 25 | 160 |
| ST40 | 40 | 250 |
Advantages:
1.Nylon backing for effective protection of the wire sheath
2.Use twist-free wire rope for better bearing and no bending
3.The claws are made of alloy steel with high strength and no deformation
Multiple Fission Conductor Lifter Other products:
| Model | Rated load (KN) | Hook groove length (mm) | Weight (kg) |
| ST25-2 | 2X12 | 120 | 13 |
| ST50-2 | 2X25 | 160 | 25 |
| ST80-2 | 2X40 | 250 | 40 |
| ST36-3 | 3X12 | 120 | 21 |
| ST75-3 | 3X25 | 160 | 35 |
| ST120-3 | 3X40 | 250 | 60 |
| ST48-4 | 4X12 | 120 | 35 |
| ST100-4 | 4X25 | 160 | 60 |
| ST160-4 | 4X40 | 250 | 90 |
| ST150-6 | 6X25 | 160 | 70 |
| ST240-6 | 6X40 | 250 | 110 |
| ST200-8 | 8X25 | 160 | 120 |
| ST320-8 | 8X40 | 250 | 160 |
Lifting wire for two bundle conductors or four bundled conductors or sex bundled conductor or eight bundled conductors.
