Model: |
JHW |
Name: |
Wire Rope Puller |
Type: |
Ratchet Withdrawing |
Rated Load: |
1~3T |
Apply: |
Tightening |
Materail: |
Steel |
1 Ton Wire Rope Ratchet Puller Hand Cable Puller For Tightening Wire
Wire Rope Ratchet Puller Hand Cable Puller Characteristic:
1 Ton Wire Rope Ratchet Puller Hand Cable Puller For Tightening Wire
Forward/reverse load holding mechanism
Heavy duty - Quality ratchet mechanism
360º Handle movement
Fast advance mechanism
Supplied with Test Certificate
Ratchet Withdrawing Wire Tool Wire Rope Tightener Technical Data
1 Ton Wire Rope Ratchet Puller Hand Cable Puller For Tightening Wire
| Model Type | Rated Load(KN) | Max Length(mm) | Min Length(mm) | Weight(kg) |
| JHW-1000 | 10 | 1210 | 410 | 3.2 |
| JHW-1500 | 15 | 1500 | 480 | 4.2 |
| JHW-1500A | 15 | 2000 | 480 | 4.7 |
| JHW-2000 | 20 | 1500 | 480 | 4.8 |
| JHW-3000 | 30 | 1500 | 510 | 5.2 |
Double Hook Wire Rope Puller Cable Puller Features
1. It has small size and light weight and convenient collection and easily carried. Its ability on operate can play its role even in a narrow place.
2. The ratchet puller is made by high quality of Taiwan galvanized wire rope and aluminum alloy pressure head. It’s strong and wearable, not fall off.
3. It is made by high tensile steel plate and the structure is used in high quality integral structure of carbon steel, then matching with the high density gear, which can rotate 360 degrees direction. The controlling keying can forward or backward turn. It is attached automatic braking device to save effort. It is suitable for electric power, telecom high homework. It is powerful and not easy to break.
4. With high tensile steel hook with latch, the strength gets greatly improved.
5. Material: High Tensile Carbon Steel
6. Constructions: heat treatment and high temperature treatment (Quenched and Tempered)
7. Finish: color zinc plated.
FAQ:
1. Are you a manufacturer or a trading company?
We are a professional fasteners manufacturer with rich experience. And in order to do business with your company well, we established a branch to open the foreign trade fields.
2. Do you offer free samples?
We can provide free samples below 10 USD and you should pay the freight. After you place an order, we will give back the freight.
3. Do you accept our design on products or boxes?
Yes. We accept customized design and we have a professional design team who can design products based on your requirements.
4. How long is your delivery time?
Generally 7-10 days if the goods are in stock or 15-30 days not in stock.In a word, according to the order quantity.
Factory price
We are the trading company with our own directly factory. So you can get high quality products with factory price. For big order and regular Customers, we give favorable discounts.
Feedback:
Your satisfaction and positive feedback is very important to us. If you have any problems with our Tools or services, please feel free to contact us. We will do our best to solve any problems and provide you the best customer services
