Name: |
ACSR Pulling Grip |
Application: |
Pulling And Traction. |
Material: |
Steel |
Length: |
Can Be Customized |
Wire Laying Construction Steel Cable Socks Wire Rope Pulling Grip Sock Wire Mesh Joints Conductor Mesh Socks Joint
Feature
1.As well as advantages of light weight, large tensile load, not damage line, convenient to use and so on.It is also soft and easy to strench.
2.The most ideal tool for electric power construction. Applicatoin Hot sale cable pulling hoisting grip,cable sock is used for buried or pipe traction on ground power cables.
It can pass all kinds of pay-off pulley.
Use Method First press the opening of the net sleeve with the palm of your hand to open it, then start to wear the cable inward.
The deeper the cable is worn, the greater the pulling force.
The mesh body of the net sleeve is in the form of a grid, and the tension is tightened during construction. After the construction is completed, you only need to apply force in the opposite direction to remove the net sleeve.
The net sleeve can be pulled by hand or lifting tool to achieve the function of wiring and protecting the cable.
|
Item number
|
Model
|
Applicable Conductor(ACSR)
|
Rated Load
(KN)
|
|
|
Single head
|
Double head
|
|||
|
17161
|
17181
|
SLW(S)-1.5
|
ACSR70-95
|
15
|
|
17162
|
17182
|
SLW(S)-2
|
ACSR120-150
|
20
|
|
17163
|
17183
|
SLW(S)-2.5
|
ACSR185-240
|
25
|
|
17164
|
17184
|
SLW(S)-3
|
ACSR300-400
|
30
|
|
17165
|
17185
|
SLW(S)-4
|
ACSR500-600
|
40
|
|
17166
|
17186
|
SLW(S)-5
|
ACSR720
|
50
|
|
17167
|
17187
|
SLW(S)-7
|
ACSR900
|
70
|
|
17168
|
17188
|
SLW(S)-8
|
ACSR1000-1120
|
80
|
|
17169
|
17189
|
SLW(S)-12
|
ACSR1250
|
120
|
