Power Of Engine (KW): |
23.5 |
Diameter Of Wheel (mm): |
300 |
Max. Diameter Of Steel Rope (mm): |
16 |
Max. Speed (km/h): |
22 |
MODEL: |
SX4-VI |
WEIGHT: |
1450 KGS |
The engine puller is designed and modified from BENYE324 four wheel drive tractor, the machine has excellent mobility on transmission line stringing site.
It is equipped with mechanical gear box and automatic brake system, easy for pulling conductor or OPGW on mountain area.
SX4-VI Tractor type Puller
Item No.: 08125
Model: SX4-VI
Technical Data:
| Gear Shifting | I | II | III | Reverse |
| Pull force (KN) | 40 | 30 | 20 | |
| Pull Speed (m/h) | 715 | 1275 | 2270 | 650 |
Features: It is designed and modified from BENYE324 four wheel drive tractor, the machine has excellent mobility on site. With mechanical transmission and dual brake system, the puller is easy to operate.
Dimension (m): 2.6 x 1.6 x 1.9
Weight (kg): 1450
