Model: |
CPC50A |
Crimping Force: |
80Kn |
Packing: |
Steel Case |
Steel Rope: |
18mm |
ACSR: |
50mm |
Armored Cable: |
50mm |
Handheld Cutting Tool Hydraulic Wire Rope Cutter Cable Cutter for Cutting ASCR
Armored Cable Cutter Hydraulic Wire Rope Cutter
|
Item number |
21447A | 21447B | 21447C |
|
Model |
CC-50A | CPC-50A | HT-50A |
|
Crimping force |
100KN | 80KN | 70KN |
|
Cutting range |
CU/AL cable Φ50mm max |
steel rope cable Φ18mm max |
steel rope cable Φ15mm max |
|
ACSR cable Φ50mm ma |
steel strand Φ10mm max |
||
|
armored CU/AL cable Φ50mm max |
ACSR cable Φ50mm max |
||
| strand Φ16mm max |
armored CU/AL cable Φ50mm max |
||
|
Stroke |
50mm | 50mm | 40mm |
|
Length |
approx.620mm | approx.620mm | approx.660mm |
|
(KG) Weight |
approx.N.W6.1KG G.W9.1KG |
approx.N.W6.2KG G.W9.2KG |
approx.N.W6.5KG G.W8.9KG |
|
Package |
plastic box | plastic box | plastic box |
Use and Characteristic
1.The tool features a double apeed action:a fast advancing speed for rapid approach of the blades to the connector and a slower more powerful speed for cutting.
2.For ease of operation and comfort the operator the tool head can be fully rotated through 360 degrees.
The built in safety valve will bypass the oil supply when the maximum pressure is reached,and the pressure release system can easily be operated at any stage of compression.
3. With interchangeable dies.
4.Steel cutting heads which can be mounted in the most convenient position for the user working in difficult locations such as shafts or towers.
5. Easy to replace blades.
6. Spring return in single acting model.
Carrying box for protection and ease of transport.
