Model No: |
SHD SHDN |
Material: |
Aluminum Or MC Nylon |
Function: |
Stringing Conductors |
Delivery: |
Within 7days |
Max Conductor: |
ACSR400-500 |
Means By Way: |
Ocean Land Air |
Small Light Single Conductor Pulleys for Stringing ACSR 25 to ACSR 500
Single Conductor Pulleys for stringing ACSR 25 to ACSR 500 are made of aluminium/ MC nylon mounted on ball bearings.
| Ordernumber | Model | Suitableconductor | Breaking load(kg) | Weight(kg) | Features |
| 10171 | SHD-120×30 | ACSR2570 | 15 | 1.5 | Aluminoussheave |
| 10172 | SHD-160×40 | ACSR95120 | 30 | 2.5 | |
| 10173 | SHD-200×40 | ACSR150240 | 45 | 4 | |
| 10174 | SHD-200×60 | ACSR150240 | 45 | 4.6 | |
| 10175 | SHD-250×40 | ACSR150240 | 60 | 4.6 | |
| 10176 | SHD-250×60 | ACSR300400 | 60 | 6 | |
| 10177 | SHD-270×60 | ACSR300400 | 60 | 7 | |
| 10178 | SHD-320×60 | ACSR300400 | 60 | 9.5 | |
| 10179 | SHD-400×80 | ACSR400500 | 60 | 15 | |
| 10191 | SHDN-120×30 | ACSR2570 | 15 | 1.5 | Nylonsheave |
| 10192 | SHDN-160×40 | ACSR95120 | 30 | 2.5 | |
| 10193 | SHDN-200×40 | ACSR150240 | 45 | 3.6 | |
| 10194 | SHDN-200×60 | ACSR150240 | 45 | 4 | |
| 10195 | SHDN-250×40 | ACSR150240 | 60 | 4 | |
| 10196 | SHDN-250×60 | ACSR300400 | 60 | 4.5 | |
| 10197 | SHDN-270×60 | ACSR300400 | 60 | 5.6 | |
| 10198 | SHDN-320×60 | ACSR300400 | 60 | 6.7 | |
| 10199 | SHDN-400×80 | ACSR400500 | 60 | 13 |
