660mm Large Diameter Stringing Blocks

Discover high-quality 660mm large diameter stringing blocks designed for efficiency and durability. Perfect for your heavy-duty stringing needs.

660mm Large Diameter Stringing Blocks

Lingkai Transmission manufactures 660mm large diameter stringing blocks composed of aluminum alloy and MC nylon, which are placed on ball bearings. The wheels are composed of galvanized steel and run on ball bearings. The stringing block groove is bordered with a neoprene ring or wear-resistant replaceable negatron or aluminium sectors.




660mm Large Diameter Stringing Blocks, three Sheaves Conductor Stringing Blocks are used for stringing two or three conductors on an overhead transmission line. The sheaves can be made of steel (central), nylon, or aluminum alloy.


660mm Large Diameter Stringing Blocks Made in China Technical Parameters To support the Transmission work.

Parameters of 660mm Large Diameter Stringing Blocks

Item Number

Model

Number of Sheave

Rated Load (kN)

Weight (kg)

Features

10121

SHD660

1

20

30

Rubber coated aluminum sheave

10122

SHS660

3

40

106

Middle: cast steel sheave with the width of 90mm Conductor: rubber coated aluminum sheave

10123

SHW660

5

60

150

10124

SHDN660

1

20

24

MC nylon sheave

10125

SHSLN660

3

40

92

Middle: MC nylon sheave Conductor: rubber coated aluminum sheave

10126

SHWLN660

5

60

120

10127

SHSQN660

3

40

76

MC nylon sheave

10128

SHWQN660

5

60

110

10129

SHQZ660

7

80

268

Middle: cast steel sheave Conductor: rubber coated aluminum sheave

10130

SHQ660A

7

75

190

Middle: cast steel sheave Conductor: MC nylon sheave

Block dimension Φ660×Φ560×110(mm) can be customized
