750mm Large Diameter Stringing Blocks
  • 750mm Large Diameter Stringing Blocks750mm Large Diameter Stringing Blocks
  • 750mm Large Diameter Stringing Blocks750mm Large Diameter Stringing Blocks
  • 750mm Large Diameter Stringing Blocks750mm Large Diameter Stringing Blocks
  • 750mm Large Diameter Stringing Blocks750mm Large Diameter Stringing Blocks

750mm Large Diameter Stringing Blocks

China Ningbo Lingkai, the sole terminal producer, produces Quality 750mm Large Diameter Stringing Blocks. We invented the newest 750mm Large Diameter Stringing Blocks and possess the patent for this power stringing line, which was submitted in China. Who prefers to buy from China rather than other abroad companies in order to meet the expectations of their clients? The main benefit of Durable 750mm Large Diameter Stringing Blocks is that they can thread the ACSR 630mm at a lower price than 822mm MC Stringing Pulleys.

750mm Large Diameter Stringing Blocks

The Ningbo Lingkai factory's 750mm Large Diameter Stringing Blocks frame is constructed of galvanized steel. We provide three types of connections: fixed (B), swivel-type (C), and hook with safety lock (D). Grounding devices and entire conductive sheaves are available on request (see list of available devices). Clevis fittings are optional; please indicate when purchasing. Customized blocks can be supplied upon request and have a 1 year warranty.



750mm Large Diameter Stringing Blocks Made in China are ideal for stringing two, three, four, or five stranded aluminum and ACSR Max 630 conductors on tangential constructions. The compression sleeves, swivel connections, and pulling rope connectors may all fit into the 750mm block groove.


Overhead line conductor stringing pulleys manufactured in China by Ningbo Lingkai are frequently utilized in 800KV-1000KV overhead power lines. Our 750mm Large Diameter Stringing Blocks have been exported to over 50 countries across the world.



Parameters of 750mm Large Diameter Stringing Blocks

Item Number

Model

Number of Sheave

Rated Load (kN)

Weight (kg)

Features

0018

SHD750

1

20

35

MC nylon

0019

SHSQN750

3

40

95

MC nylon

0020

SHWQN750

5

60

145

Block dimension Φ750×Φ640×110(mm) can be customized
