1. Despite high quality Hand Winch Walking Tractor modifications, this machine still retains the qualities of the hand-supported tractor's structure.
2. China Hand Winch Walking Tractor is light to manipulate, flexible, and has excellent driving performance.
3. Hand Winch Walking Tractor is also suitable for various operations, such as transmission line construction tower, launch, tightening, traction, lifting, and transportation.
4. Hand Winch Walking Tractor Made in China Summary:
· Walking winch converted from hand-supported tractor
· Redesigned gearbox with three-level gear deceleration and gravity brake mechanism
· Extended half-axis on front gearbox to drive the tire
· Extended grinding cylinder shaft to drive the grinding cylinder for twisted operation
· Retains hand-supported tractor's structure for light manipulation and flexible driving performance
· Suitable for various operations such as transmission line construction tower, launch, tightening, traction, lifting, and transportation
5. Durable Hand Winch Walking Tractor data sheet made by Ningbo Lingkai Supplier
|
Item number |
Model |
Ground Clearance(mm) |
Wheel-base (mm) |
Power (HP) |
Speed (RPM) |
Travel speed(Km/H) |
Outline size(mm) |
Weight(kg) |
|
09171 |
12-A |
150 |
1040 |
15 |
2000 |
3-13 |
2670x1040x1300 |
550 |
|
09172 |
12-B |
150 |
1040 |
15 |
2000 |
3-13 |
2670x1040x1300 |
600 |
|
Gear |
Ⅰ |
Ⅱ |
Ⅲ |
IV |
reversalⅠ |
reversalⅡ |
||
|
Traction force(KN) |
60 |
37 |
20 |
12 |
/ |
/ |
||
|
Traction speed(m/min) |
11.7 |
18.9 |
34.4 |
55.6 |
6.2 |
21.3 |
||
6. Hand Winch Walking Tractor Packing:
- Cable Winch Puller
- User Manual
- Warranty Card
- Customized exported wooden case
