Anti Twist Steel Rope Grippers

Our Anti Twist Steel Rope Grippers made in China are clamps that grasp wire ropes and precisely and steadily regulate their movement. They are manufactured in China by Ningbo Lingkai Manufacture. The purpose of all-come-along clamps is to keep your wire ropes under control and safe, even in the face of severe strain.

Anti Twist Steel Rope Grippers

Ningbo Lingkai Manufacture's Anti Twist Steel Rope Grippers are used at the location of overhead transmission lines. The type "V" clipper gap, the low weight, the two-side load symmetry active force characteristics, and the grip anti-twist rope are all used with them. Verify that installing and using the Anti Twist Steel Rope Grippers is simple. Even if you've never used a gripper before, you can clamp and secure your wire rope fast and safely thanks to the user-friendly design of the clamping mechanism. Another feature of the Anti twist Steel Rope Grippers is their ability to reduce damage to your wire rope. By uniformly distributing the weight, the clamping mechanism lowers the possibility of harm from high pressure.




Our Model SKG Anti Twist Steel Rope Grippers in buck wholesale. Commonly data sheet as below.


Item number

Model

Rated Load

(KN)

Applicable Anti Twist Steel Rope

Weight

(kg)

13155

SKG50N

50

□ 11-15

7.0

13156

SKG70N

70

□ 16-18

8.0

13157

SKG120N

120

□ 19-21 or □ 22-24

11.6

13158

SKG200N

200

□ 26-28 or □ 30

23.5



Additionally, we produce other models of anti twist steel rope grippers, too. The ground wire grips of transmission line stringing tools, models SKDZ, SKDS, and SKD Automatic, come along with clamps for ground wires; they are all highly forged with alloy steel, especially the jaws to hold the ground wire. Please freely ask us to inquiry the Earth Wire Grips price.

SKDS Dual Cam Type Earth Wire Grips

Item No.

Model

Rated Load (KN)

Breaking Load (KN)

Wire Size Range (mm²)

Max. Opening (mm)

Weight (kg)

13141

SKDS-1

10

20

25-50

11

2.6

13142

SKDS-2

20

40

70-120

13

3.1

13143

SKDS-3

30

60

95-150

15

4.1


SKD type Ground Wire Grips (Automatic come along clamps for ground wires)


Item No.

Model

Rated Load (KN)

Breaking Load (KN)

Wire Size Range (mm²)

Max. Opening (mm)

Weight (kg)

13113

SKD25

10

30

25

9.5

2.5

13114

SKD35

10

30

35

9.5

2.5

13115

SKD50

15

45

50

10

3.5

13116

SKD70

20

60

70

12.5

5.0

13117

SKD100

30

90

100

14

6.0


SKDZ Model Earth Wire Grips (Automatic come along clamps for ground wires)


Item No.

Model

Rated Load (KN)

Breaking Load (KN)

Wire Size Range (mm²)

Max. Opening (mm)

Weight (kg)

13101

SKDZ-0.5

5

15

10-25

10

2

13102

SKDZ-1

10

30

25-50

12

2

13103

SKDZ-2

20

60

50-70

14

2.9

13104

SKDZ-3

30

90

70-120

16

3.5

13105

SKDZ-5

50

150

150-185

20

6.3
