A high-quality Electric Hydraulic Pump Station it is equipped with an electromagnetic valve control to draw pistons in any position. It has two high- and low-speed stages for quick oil output. Turbine oil absorption could ensure maximum, effective oil volume.
The pressure safety valve in Electric Hydraulic Pump Station has an overpressure unit to avoid overpressure damage and a pressure release of 700 kg/cm2. High pressure is for driving pistons, and lower pressure is for piston reset. And oil fitted with quick coupling could be ordered in any length and with PT3/8’’ thread.
|
Model |
Oil outlet way |
Pressure rating |
Power
|
Oil delivery |
Reservoir capacity |
Weight |
|
EHP-70AS |
Single hole |
700/10000kgf/cm2/psi |
0.75kw |
Low:5 High:0.8(cc/stroke) |
8000cc |
29kgs |
|
EHP-700ZS |
Two hole |
700/10000kgf/cm2/psi |
0.75kw |
Low:5 High:0.8(cc/stroke) |
8000cc |
30kgs |
|
EHP-63A |
Single hole |
700/10000kgf/cm2/psi |
0.75kw |
Low:5 High:0.8(cc/stroke) |
6000cc |
28kgs |
|
SH-700 |
Single hole |
700/10000kgf/cm2/psi |
1.2kw |
Low:5 High:0.7(cc/stroke) |
2000cc |
12kgs |
|
SH-700A |
Single hole |
700/10000kgf/cm2/psi |
0.40kw |
Low:3.5 High:0.5(cc/stroke) |
2000cc |
15kgs |
