Ningbo Lingkai's sturdy Opgw cable block 1 Years Warranty, also known as OPGW stringing pulley blocks, is used to thread OPGW or ADSS cable on overhead transmission lines. The sheaves are composed of MC nylon or aluminum alloy. The pulley's diameter is large enough to hang OPGW cable while meeting the bend radius requirement. It can be fitted with grounding rollers.
Opgw Cable Block , and Stringing Block for OPGW cable
Item No.: 20131
Application: It is used to support the OPGW cable on the tangent structure in stringing operation.
Features: Φ660mm diameter nylon sheave, with contoured groove bottom .
Weight (kg): 32.
The Opgw cable block Made in China may be used to string both normal aluminum and ASCR cables, as well as tangent constructions. Compression sleeves, swivel connections, and pulling rope connectors may all fit in the groove. The sheave is manufactured from high-strength nylon. The large 660mm, 822mm, 916mm, and 1040mm nylon sheaves may be lined with neoprene.
|
Item No. |
Model |
ACSR Size Range (mm²) |
Working Load (KN) |
Weight (kg) |
Material of Sheave |
|
10191 |
SHDN-120x30 |
25-70 |
5 |
1.5 |
Nylon |
|
10192 |
SHDN-160x40 |
70-95 |
10 |
2.4 |
|
|
10193 |
SHDN-200x40 |
95-120 |
15 |
2.6 |
|
|
10194 |
SHDN-200x60 |
120-150 |
15 |
3.1 |
|
|
10195 |
SHDN-250x40 |
120-150 |
20 |
3.7 |
|
|
10196 |
SHDN-250x60 |
150-180 |
20 |
3.9 |
|
|
10197 |
SHDN-270x60 |
180-240 |
20 |
4.4 |
|
|
10198 |
SHDN-320x60 |
240-300 |
20 |
7.5 |
|
|
10199 |
SHDN-400x80 |
300-400 |
20 |
8 |
|
|
10104 |
SHDN508 |
300-400 |
20 |
16 |
Nylon, optional can be lined with neoprene |
|
10124 |
SHDN660 |
400-500 |
20 |
24 |
|
|
10131 |
SHDN750 |
500-600 |
30 |
32 |
|
|
10141 |
SHDN822 |
600-700 |
30 |
38 |
|
|
10151 |
SHDN916 |
700-800 |
50 |
51 |
|
|
10165 |
SHDN1040 |
800-900 |
50 |
60 |
