The Composition and Benefits of Anti Twist Braided Steel Rope 12MM for pulling single conductor or OPGW factory Lingkai made in China
The Anti Twist Braided Steel Rope 12MM for pulling single conductor or OPGW is a unique kind of wire rope that boasts a primary structure consisting of multiple wire strands that are wound together. In addition, there is a specially designed steel core wound in the middle of the wire rope, which performs the essential task of preventing the steel wire rope from developing any sort of twisting deformations.
The Anti Twist Braided Steel Rope 12MM for pulling single conductor or OPGW offers a host of benefits, including excellent fatigue resistance, longevity, durability, and high tensile strength. As a result, Anti twisting braided steel wire rope is perfect for a wide range of applications and is known for its reliable performance. The excellent flexibility and high load-bearing capacity also make this wire rope ideal for use in diverse fields.
|
Item No. |
Nominal diameter |
Breaking Load (KN) |
Single strand diameter (mm) |
Normal T/S (N/mm²) |
Net Weight (kg/1000m) |
|
18201A |
9mm |
50 kN |
2.0mm |
1960 |
250 |
|
18202A |
10mm |
70 kN |
2.3mm |
1960 |
356 |
|
18203A |
11 mm |
85 kN |
2.5mm |
1960 |
410 |
|
18204A |
12 mm |
100 kN |
2.7mm |
1960 |
510 |
|
18205A |
13 mm |
115 kN |
3.0mm |
1960 |
620 |
|
18206A |
14 mm |
130 kN |
3.2mm |
1960 |
710 |
|
18207A |
15mm |
143 kN |
3.3mm |
1960 |
770 |
|
18208A |
16mm |
160 kN |
3.5mm |
1960 |
800 |
|
18209A |
18mm |
206 kN |
4.0mm |
1960 |
1060 |
|
18210A |
19mm |
236 kN |
4.3mm |
1960 |
1210 |
|
18211A |
20mm |
266 kN |
4.5mm |
1960 |
1310 |
|
18212A |
22 mm |
313 KN |
4.8 mm |
1960 |
1500 |
|
18213A |
24 mm |
342 KN |
5.0 mm |
1960 |
1650 |
|
18214A |
26 mm |
400 KN |
5.4 mm |
1960 |
1950 |
|
18215A |
28 mm |
462 KN |
6.0 mm |
1960 |
2020 |
