Anti-Twisting Steel Wire Rope is made in China at the Ningbo Lingkai Plant, which is a very big OEM plant. We have 10 machines to run every day and night to process the steel wire editing into Anti-Twisting Steel Wire Rope. This raw material for the steel wire is from one of the two government-authorized steel rope plants. So the single steel wire has a very high top strength. Our Anti-Twisting steel wire rope can homogeneously distribute the pressure between the elementary wires. The special rope can increase efficiency during the overhead transmission line stringing work.
Anti-twisting steel wire rope can be totally customized per client's diameter size, and it is used as a pilot wire rope for pulling conductors or OPGW cable in overhead transmission line stringing operations.
|
Item number |
Structure |
Diameter (mm) |
Single bundle diameter (mm) |
Breaking force (kN) |
Weight (kg/m) |
Production length (m) |
|
18101 |
Square eight strands |
7 |
φ2.0 |
34.38 |
0.178 |
1000 |
|
18102 |
9 |
φ2.5 |
53.9 |
0.305 |
||
|
18103 |
11 |
φ3.0 |
76.94 |
0.386 |
||
|
18104 |
13 |
φ3.5 |
105.04 |
0.552 |
||
|
18105 |
15 |
φ4.0 |
137.51 |
0.692 |
||
|
18108 |
Square twelve strands |
9 |
φ2.0 |
51.57 |
0.25 |
|
|
18109 |
11 |
φ2.5 |
80.8 |
0.458 |
||
|
18110 |
13 |
φ3.0 |
115.4 |
0.579 |
||
|
18111 |
15 |
φ3.5 |
157.55 |
0.828 |
||
|
18112 |
18 |
φ4.0 |
206.27 |
1.038 |
||
|
18113 |
20 |
φ4.5 |
260.3 |
1.331 |
800 |
|
|
18114 |
23 |
φ5.0 |
320.82 |
1.557 |
||
|
18115 |
25 |
φ5.5 |
387.83 |
1.882 |
||
|
18118 |
Hexagon twelve strands |
11 |
φ2.5 |
80.8 |
0.458 |
1000 |
|
18119 |
13 |
φ3.0 |
115.4 |
0.579 |
||
|
18120 |
15 |
φ3.5 |
157.5 |
0.828 |
||
|
18121 |
18 |
φ4.0 |
205.71 |
1.038 |
||
|
18122 |
20 |
φ4.5 |
260.34 |
1.331 |
800 |
|
|
18123 |
23 |
φ5.0 |
320.82 |
1.638 |
||
|
18124 |
25 |
φ5.5 |
387.82 |
2.039 |
600 |
|
|
18125 |
27 |
φ6.0 |
461.5 |
2.373 |
||
|
18126 |
28 |
φ6.2 |
520 |
2.6 |
||
|
18127 |
30 |
φ6.5 |
560 |
3.12 |
||
|
18140 |
Hexagon eighteen strands |
21 |
φ3.0 |
173.1 |
0.87 |
800 |
|
18141 |
24 |
φ3.5 |
236.33 |
1.242 |
||
|
18151 |
27 |
φ4.0 |
309.4 |
1.557 |
600 |
|
|
18152 |
30 |
φ4.5 |
389.28 |
1.997 |
||
|
18153 |
33 |
φ5.0 |
481.22 |
2.457 |
||
|
18154 |
36 |
φ5.5 |
581.75 |
3.059 |
||
|
18154A |
39 |
φ6.0 |
692.26 |
3.56 |
||
|
18154B |
42 |
φ6.5 |
817 |
4.227 |
●Uses: Anti-Twisting Twisting steel rope is applied to mechanical pulling and tensioning release conductors as pulling rope or leading rope.
●Feature: Braided 1960 Mpa high-strength galvanized steel wire. rotation resistance during pulling.
●The specification and length of the steel wire rope can be customized according to your request.
